TP-Link has introduced a new addition to its Omada Access Pro switch lineup with the TL-SG3428XPP-M2. The current model is listed as the SG3428XPP-M2 and brings 24 2.5Gbps PoE++ ports, four 10Gbps SFP+ slots, and a 770W total PoE budget.
The switch targets networks that require fast wired connections and power for connected devices. Its Omada management tools also give administrators several ways to control the network. This new switch builds on the role of models such as the SG3428x-M2 while adding high-power PoE support for demanding network deployments.
What is TL-SG3428XPP-M2?
The TL-SG3428XPP-M2 name refers to TP-Link's earlier product listing for this Omada managed switch. TP-Link now lists the newer version as the SG3428xPP-M2, with the product page identifying it as new.
The current SG3428XPP-M2 provides 24 2.5Gbps RJ45 ports and four 10Gbps SFP+ slots. All 24 RJ45 ports support PoE++ in the current version, with up to 90W available per port and a 770W total PoE budget.
The switch is rack-mountable and supports centralized management through Omada. It also supports standalone management through:
- Web tools
- CLI
- SNMP
- RMON
It is important to check the exact hardware version before relying on specifications. For readers searching for a TP-Link TL SG3428 review. This is because the newer SG3428XPP-M2 has different PoE specifications from the older TL-SG3428XPP-M2 listing.
Key Features of TP-Link Omada SG3428XPP M2
The switch combines multi-gigabit Ethernet and high-power PoE with 10G uplinks and centralized network control in one rack-mountable unit. These features give network administrators several tools for building larger wired networks. Let’s go over the key features that it offers.
Ports
The current TP-Link Omada SG3428XPP M2 provides 24 × 2.5Gbps RJ45 ports and four × 10Gbps SFP+ slots. The RJ45 ports support multi-gigabit Ethernet connections. This makes them suitable for devices that can use speeds above standard Gigabit Ethernet.
The four SFP+ slots provide faster uplink options for connecting the switch to other network equipment. These ports can support high-bandwidth connections across a network backbone.
The switch also includes an RJ45 console port and a Micro-USB console port for management access. Its 200Gbps switching capacity and 148.8Mpps packet forwarding rate give administrators substantial capacity for busy network environments.
Power over Ethernet (PoE)
PoE lets compatible network devices receive power and data through an Ethernet connection. This can simplify installations because a compatible device does not always require a separate power cable.
The current SG3428XPP-M2 provides PoE++ across all 24 2.5Gbps RJ45 ports. TP-Link lists support for IEEE 802.3bt, 802.3at, and 802.3af standards. Each port can provide up to 90W under the specified PoE++ capability.
This high-power support can suit demanding devices such as advanced wireless access points and other PoE equipment. The older TL-SG3428XPP-M2 specification had a different arrangement, with eight PoE++ ports and sixteen PoE+ ports.
Power Budget
The current model provides a total PoE budget of 770W. That number represents the total amount of power available for connected PoE devices. It does not mean every connected device will automatically receive 90W.
Actual power use depends on the connected devices and their requirements. A network administrator therefore needs to check the power needs of the planned installation.
A high total budget becomes useful in networks with many powered devices. Access points, cameras, phones, and other compatible equipment can share the available PoE capacity.
The current 770W budget is also a key specification to check when comparing this model with older versions. The previous TL-SG3428XPP-M2 listing showed a 500W total PoE budget.
Management
The switch supports centralized management through the Omada platform. Administrators can manage supported network equipment through a web interface or the Omada app. TP-Link also lists standalone management through web access, CLI, SNMP, and RMON.
This range of options gives network teams flexibility in how they operate the switch. A smaller setup may rely heavily on the web interface, while a larger organization may use additional management tools.
The Omada system can also provide centralized visibility across supported devices. TP-Link describes cloud access as a way to manage access points, switches, and gateways across multiple sites from one interface.
The result is a management setup that fits both local administration and broader Omada deployments.
Advanced L2+ Features
The SG3428XPP-M2 includes several Layer 2 and Layer 2+ networking features. TP-Link supports various functions. This includes:
- VLAN
- ACL
- QoS
- IGMP Snooping
- OAM
- DDM
- Static routing
Static routing can help route internal traffic without sending every request through another routing device. VLAN support lets administrators divide network traffic into logical groups. This can help separate users, devices, or services within the same physical network.
QoS provides tools for managing traffic priorities. This can be useful for applications that depend on steady network performance.
The switch also supports ERPS for rapid protection and recovery in supported ring network designs. Security features include IP-MAC-Port Binding, ACLs, port security, DHCP Snooping, 802.1X, and related controls on the applicable product version.
Who Should Choose TP-Link Omada SG3428XPP M2
A switch with 24 multi-gigabit PoE++ ports and four 10G SFP+ slots is aimed at networks that have significant connectivity and power requirements. Its feature set can suit several types of deployment. The following groups may find the TL SG3428x M2 family relevant when planning a new network or upgrading existing equipment.
Businesses With Multi-Gigabit Networks
Businesses with modern access points or other multi-gigabit devices may benefit from 2.5Gbps Ethernet ports. A traditional Gigabit connection can become a limitation for equipment that supports faster Ethernet speeds. The SG3428XPP-M2 provides 2.5Gbps connectivity on all 24 RJ45 ports.
This gives compatible devices access to higher wired speeds. The four 10Gbps SFP+ slots also provide faster uplink options. This can be useful when the switch connects to a:
- Core switch
- Server
- Storage system
- Another high-capacity network device
Businesses can therefore build a multi-gigabit access layer. It does this while keeping faster links available for the network backbone.
Offices With Many PoE Devices
Modern offices can have a long list of network-powered equipment. Many compatible devices can use PoE. This includes:
- Wireless Access Points
- Security Cameras
- VoIP Phones
The current SG3428XPP-M2 provides 24 PoE++ ports and a 770W total PoE budget. That setup can reduce the number of separate power connections required around an office.
A centralized PoE switch can also make device management easier because network and power connections come together in one rack location.
Before installation, administrators should still calculate the expected power load. The total requirement should remain within the switch's available PoE budget.
Networks Using Wi-Fi 6 and Wi-Fi 7 Access Points
Newer wireless access points can support multi-gigabit Ethernet connections. A wired link that matches the access point's capabilities can prevent the Ethernet connection from becoming a speed limit.
TP-Link specifically positions the switch for Wi-Fi 7, Wi-Fi 6E, and Wi-Fi 6 access points. The 2.5Gbps PoE++ ports provide both network connectivity and power for compatible access points.
This setup can be useful in offices, schools, hospitality locations, and other spaces with many wireless users. The four 10Gbps SFP+ slots can then connect the access layer to faster upstream equipment.
Organizations Building Larger Omada Networks
Organizations already using Omada equipment may find centralized management useful. Omada provides a common management environment for supported switches, access points, and gateways.
TP-Link states that its cloud-based system can manage supported devices across multiple sites from a single interface. That feature can reduce the need to manage every device separately.
Zero-touch provisioning is also listed among the Omada capabilities for the product family. Organizations with several network locations can therefore build a consistent management process around the Omada platform.
Installations That Require High-Power PoE
Some PoE devices require more power than basic PoE equipment. The current model's support for up to 90W per port gives it a higher power ceiling for compatible devices.
This can make the switch useful for deployments with demanding powered equipment. However, the connected device must support the required PoE standard. The cable installation must also meet the appropriate requirements.
Administrators should check the device specification before planning a high-power PoE deployment. The large overall PoE budget also provides room for many powered devices, although the total load still needs to remain within the switch's 770W limit.
Build Your Network With TS Cables
The SG3428xPP-M2 brings multi-gigabit connectivity, 10G uplinks, and high-power PoE into a single managed switch. The newer model also raises the available PoE budget to 770W. For installations built around this hardware, reliable Ethernet cabling remains an important part of the physical network.
TS Cables supplies networking cable solutions for projects that require dependable wired connections and clean installations.
FAQs
Is the SG3428XPP-M2 the same as the TL-SG3428XPP-M2?
TP-Link now lists the newer model as SG3428XPP-M2. TL-SG3428XPP-M2 refers to the earlier product listing and specification.
How many ports does the SG3428XPP-M2 have?
The current model has 24 2.5Gbps PoE++ RJ45 ports and four 10Gbps SFP+ slots for high-bandwidth uplink connections.
What is the PoE budget of the new SG3428XPP-M2?
The current model has a 770W total PoE budget. This can go up to 90W available per PoE++ port under supported conditions.
Does the SG3428XPP-M2 support Omada management?
Yes. The switch supports centralized Omada management through web access and the Omada app. This is alongside several standalone management methods.
How does SG3428XPP-M2 differ from SG3428X-M2?
The SG3428XPP-M2 adds PoE++ capability and a large PoE budget. The SG3428X-M2 provides 24 2.5Gbps ports without the same PoE functionality.
