Fire alarm circuits must keep working when a fire threatens the building. Cable selection therefore affects more than signal transmission during normal operation. A CI fire cable is built and listed for circuit survivability under fire conditions for a specified period.
Standard fire cable may serve regular fire alarm pathways without carrying a circuit integrity classification. The difference becomes important in systems where critical signals must remain active during an emergency.
Terms such as CI cable, circuit integrity cable, and CI fire alarm cable describe specialized cable classifications that support continued operation when fire threatens the wiring itself and surrounding building areas.
What is CI Fire Cable?
A CI fire cable is listed for circuit integrity and is intended to keep a critical circuit operating for a specified period during fire exposure. The National Electrical Code recognizes CI cables as one method for meeting certain fire alarm circuit survivability requirements.
Key Features of This Type of Cable
Several details separate a CI cable from ordinary fire alarm wiring. The suffix “-CI” is especially important because it identifies an additional circuit integrity classification. UL recognizes CI cable categories for power-limited and nonpower-limited fire alarm applications.
The following features show what installers should look for when reviewing a product specification, jacket marking, or certification record before installation.
- Circuit Integrity: Carries a CI classification that identifies the cable as suitable for listed circuit survivability applications during fire conditions.
- Fire Resistance: The construction is tested for continued circuit operation during defined fire exposure rather than only normal flame performance.
- Cable Marking: A listed product carries markings that identify its applicable cable type, classification, and other required information.
- Installation Limits: The cable must be installed according to its listing because installation conditions can affect the fire-resistive rating.
- Critical Circuits: A CI cable is intended for applications where continued electrical operation remains important during a fire.
Pros of This Type of Cable
Circuit integrity construction brings an important advantage to life-safety systems. It is intended for situations where losing a fire alarm circuit during a fire could interfere with critical system functions. That purpose gives CI products a specialized role in fire alarm installations.
- Fire Survivability: A circuit integrity cable is tested to maintain circuit operation during specified fire exposure for its listed duration.
- Critical System Support: The cable can support fire alarm circuits that have defined survivability requirements under applicable codes.
- Clear Identification: The CI marking gives installers and inspectors a direct indication that the cable carries a circuit integrity classification.
- Specialized Protection: The construction focuses on maintaining electrical function rather than simply slowing flame spread along the cable.
- Code Applications: Listed CI products can be used in applications where circuit survivability is required and the installation follows the applicable listing.
Cons of This Type of Cable
CI cable provides specialized fire performance, but that performance comes with installation and specification requirements. The cable should never be selected only because it sounds safer. Its listing must match the circuit, pathway, and system requirements.
- Higher Cost: A CI product may cost more than standard fire alarm cable because its construction and testing address additional fire-survivability requirements.
- Installation Restrictions: A CI fire cable must follow its listing and installation instructions to maintain its rated performance.
- Limited Interchangeability: A CI cable should not be treated as a universal replacement for every fire alarm cable type or pathway.
- Specification Work: Project documents may require a specific CI rating, cable construction, or compatible fire-resistive system.
- Availability: Specialized CI products may offer fewer options than standard fire alarm cables in some markets.
Applications of This Type of Cable
CI cable is most useful where fire alarm circuits must remain functional for a defined period after fire exposure begins. The exact application depends on the system design, code requirements, and product listing.
- Emergency Circuits: A CI fire alarm cable can serve critical fire alarm circuits that require continued operation during a fire.
- Survivability Pathways: CI products may be specified where fire alarm circuit survivability is required by the project or applicable code.
- Critical Notification: The cable can support circuits serving equipment that must continue operating during an emergency.
- Large Facilities: Hospitals, high-rise buildings, and other complex facilities may have fire alarm pathways with specific survivability requirements.
- Listed Systems: CI cable may form part of a listed fire-resistive installation when the complete installation follows applicable requirements.
What is Non-CI Fire Cable?
Non-CI fire cable refers to fire alarm cable that does not carry a circuit integrity classification. It can still have an appropriate fire alarm listing, such as FPL, FPLR, or FPLP, depending on its construction and installation location. The absence of “-CI” does not mean the cable is unsafe or unsuitable.
Key Features of This Type of Cable
Non-CI fire cable is commonly selected for fire alarm circuits that do not have a defined circuit survivability requirement. Its correct use still depends on the cable's listing, location, system requirements, and applicable electrical code.
- Standard Construction: A non-CI fire cable may contain copper conductors, insulation, shielding where specified, and an outer jacket suited to its listing.
- Fire Alarm Listings: Products may carry classifications such as FPL, FPLR, or FPLP when they meet the applicable requirements.
- No CI Classification: The cable does not carry the additional “-CI” classification used to identify circuit integrity cable.
- Pathway Selection: The cable rating must match the installation environment, such as general-purpose, riser, or plenum spaces.
- System Compatibility: The product must still meet the fire alarm system manufacturer's requirements and applicable installation rules.
Pros of This Type of Cable
Non-CI fire alarm cable remains a practical choice for many installations. Its main advantage is that it provides suitable fire alarm wiring without adding circuit integrity features that may not be required for the particular application.
- Lower Cost: Standard fire alarm cable can be more economical when circuit integrity protection is not required.
- Broad Selection: Installers can choose from many cable constructions and fire alarm ratings based on the installation.
- Simpler Specification: Projects without survivability requirements may have fewer cable performance requirements to verify.
- Flexible Options: FPL, FPLR, and FPLP products address different installation environments when properly listed.
- Routine Applications: Non-CI products suit many fire alarm pathways where continued operation during fire exposure is not specifically required.
Cons of This Type of Cable
Non-CI cable has limits that become important when a project requires circuit survivability. A standard fire alarm listing does not automatically provide the same fire-resistive performance associated with a CI classification.
- Limited Survivability: A non-CI cable is not classified specifically for maintaining circuit operation for a defined period under fire conditions.
- Unsuitable for Some Critical Circuits: Certain fire alarm survivability applications require CI cable or another listed fire-resistive solution.
- Greater Selection Risk: Choosing a cable only by conductor size can lead to an incorrect pathway or performance rating.
- Fire Rating Confusion: An FPLR or FPLP designation does not automatically mean the cable carries a CI classification.
- Replacement Concerns: Installing a non-CI cable where CI performance is required can create compliance and system-design problems.
Applications of This Type of Cable
Non-CI cable works well for fire alarm pathways where the system design does not require circuit integrity. The specific cable type should match the installation location and system requirements.
- General Areas: Suitable listed cable can serve fire alarm circuits installed in permitted general-purpose locations.
- Riser Pathways: An FPLR-rated product may be used in suitable vertical pathways when the listing and code requirements are satisfied.
- Plenum Spaces: An FPLP-rated product is intended for qualifying plenum and environmental air spaces.
- Routine Fire Alarm Circuits: Non-CI products can serve standard circuits that do not require defined fire survivability.
- Commercial Installations: Offices, retail spaces, and other buildings may use listed non-CI cable where project requirements permit it.
CI vs. Non-CI Fire Cable: Key Differences To Understand
The main difference involves circuit survivability during fire exposure. A CI product carries an additional classification for maintaining circuit operation for a specified period. A non-CI cable may still have a valid fire alarm listing, but it does not carry that same circuit integrity classification.
Function and Purpose
Function and purpose provide the clearest starting point for this comparison. The cable must match what the fire alarm circuit is expected to do during an emergency. A circuit that must survive fire exposure requires a different performance classification from a standard pathway.
CI Fire Cable
A CI fire alarm cable is intended to maintain electrical circuit function for a specified period under fire conditions. This classification supports fire alarm survivability requirements when the cable is properly listed and installed.
Non-CI Fire Cable
Non-CI fire cable serves standard fire alarm wiring applications where a circuit integrity classification is not required. It still needs the correct fire alarm listing for the intended installation location.
Construction and Materials
Cable construction affects how a product behaves under fire exposure. CI construction is tested for circuit survivability, while non-CI products are built around their specific fire alarm cable listing. The exact materials vary between manufacturers, so product documentation should always be checked.
CI Fire Cable
A CI product uses construction that supports continued circuit operation during specified fire exposure. Some products may use specialized insulation, shielding, barriers, or other materials that support their listed fire-resistive performance.
Non-CI Fire Cable
A non-CI product uses construction appropriate to its specific fire alarm classification. Copper conductors, insulation, shielding, and jacket materials vary by product and application, so the cable's marking remains important.
Testing and Standards
Testing is where the CI designation gains its technical meaning. UL identifies circuit integrity cable as a specialized category and notes that these cables are defined by their duration of fire survivability when installed within the conditions of their listing.
CI Fire Cable
A CI cable is evaluated for circuit integrity during fire exposure under the applicable listing requirements. UL identifies several CI categories, including power-limited and nonpower-limited fire alarm cables. UL 2196 is one recognized test standard associated with circuit integrity and fire-resistive cable performance.
Non-CI Fire Cable
Non-CI cable is tested and listed according to its applicable fire alarm cable standard and classification. For example, UL identifies power-limited fire alarm cable under UL 1424 and nonpower-limited fire alarm cable under UL 1425.
Applications and Requirements
The right choice depends on the circuit's required function, the installation location, and the applicable code. A cable's label should be checked against the project documents rather than selected from conductor size alone.
CI Fire Cable
A CI product is appropriate where the fire alarm design requires continued circuit operation during fire conditions for a defined period. NEC provisions recognize CI cable as one method for meeting certain survivability requirements.
An FPLR circuit integrity cable is an example of how a fire alarm cable's base classification and CI classification can appear together. FPLR identifies the riser application, while CI identifies the additional circuit integrity classification. The two terms describe different performance and installation characteristics.
Non-CI Fire Cable
A non-CI product can serve fire alarm circuits that do not have a circuit survivability requirement. The installer still needs to match the cable to the pathway. FPLR, for example, addresses riser use, while FPLP addresses qualifying plenum and environmental air spaces.
The key point is simple: an FPLR cable is not automatically a CI cable. If circuit integrity is required, the product must carry the appropriate CI classification or be part of another listed fire-resistive solution permitted by the applicable code.
Choose the Right Fire Alarm Cable with TS Cables
CI and non-CI cables serve different fire alarm requirements. A CI fire cable is intended for defined circuit survivability, while standard fire alarm cable serves applications without that classification. Check every cable's listing, installation limits, and project requirements before specifying it.
TS Cables provides reliable cable options for fire alarm systems where proper performance matters most during emergencies.
FAQs
What does CI mean on fire alarm cable?
CI means circuit integrity. It identifies cable that is listed to maintain circuit operation for a specified period under defined fire conditions.
Is every FPLR cable a CI cable?
No. FPLR identifies a riser-rated fire alarm cable. A product needs the additional CI classification when circuit integrity performance is specifically required.
Can CI cable be installed in raceway?
CI cable installation depends on its listing. Some CI cables have specific free-air limitations unless they are listed as part of a fire-resistive system.
Is non-CI fire cable unsafe?
No. Non-CI cable can be appropriate for many fire alarm applications. Its listing must match the circuit, pathway, and applicable project requirements.
What is an FPLR circuit integrity cable?
An FPLR circuit integrity cable combines an FPLR fire alarm classification with an additional CI classification for applications requiring circuit survivability.
